Shinden J7W - DXF Plans and CAD Files

shinden japanese rc dxf files cad model

Introducing the Kyushu J7W Shinden, a WWII-era Japanese interceptor known for its striking canard configuration and innovative design. With a 2000mm (80") wingspan, this model is perfect for RC Shinden J7W enthusiasts who appreciate historical aviation and want to recreate a piece of WWII history.


What’s Included:

  • DXF Plans: Laser-cut the airframe from 3mm (or 1/8") plywood using the included DXF plans
  • STL Files: 3D-print essential components like the cowl, canopy, winglets, exhaust, and more
  • 3D-Printed Landing Gear Files: Files for easy conversion to metal gears

This Kyushu J7W Shinden model offers a unique building experience and the chance to bring a legendary aircraft to life with precise DXF plans. Perfect for hobbyists and collectors!

    Shop - Cults 3DShop - EtsyDirect Payment - Save 30%

    Incomplete Sample DXF Plans - For Complete Plans Visit Shop

    RAF_sample_shinden (zip)

    Download
